Semi-auto Folder Gluer Machine
Technical data
| Model | MG-2000 | MG-2600 |
| Speed | 0-50m/min | 0-50m/min |
| Max feeding size | 2000 x 1300mm | 2600 x 1300mm |
| Min feeding size | 600 x 250mm | 600 x 250mm |
| Motor power | 2.5kw | 2.5kw |
| Dimension | 4800x1800x1800mm | 4800x2000x1800mm |
Technical data
| Model | ST-2800 |
| Max sheet width (B+C) x2 | 2800mm |
| Min sheet width (B+C) x2 | 606mm |
| Max length (F) | 1515mm |
| Min length (F) | 300mm |
| Side mark (C) | 125-500mm |
| Stitching flap (D) | 30-50mm |
| Paperboard thickness | 3-10mm |
| Machine speed | 500 stitches/min |
| Stitching pitch | 30-100mm |
| Number of stitching | 2-99 stitches |
| Stitching wire width | 2mm or 1.8mm |
| Stitching forming | ① // // // ② / / / ③ // / // |
| Height of feeder | 900mm |
| Total power | 4.5kw |
| Voltage | 380V, 50HZ, 3phase |
| Weight | 2000kg |
| Machine size | 2520x1790mm |
| Floor dimension | 2800 x 2600 x 2000mm |
